Surface Topography – Nomarski Image of Molded Polymer

Topography of a molded polymer surface shown by using Nomarski Differential Interference Phase Contrast

The surface topography of a molded polymer is shown by the Nomarski differential phase contrast imaging mode. Nomarski can often add to the depth of field of rough or uneven surfaces to show more detail in the image.
